| TYPE & RANGE: | |
| DN: Differential Non-isolated 200", 2000" w.c. | |
| GI: Gauge Isolated 20 PSI, 200 PSI, 2000 PSI | |
| AI: Absolute Isolated 2000 mm Hg
|
|
| ACCURACY:± 0.1% of reading ± 1
least significant digit (includes combined effects of linearity, repeatability, hysteresis
and temperature ). NIST certification supplied.
|
|
| TEMPERATURE: | |
| Storage: -40º F to 140º F (-40º'C to 60º'C) | |
| Operating: -4º'F to 122º F (-20º C
to 50º C)
|
|
| PRESSURE LIMITS: Twice range on AI
and GI units. Twice range on DN units when pressurized on high side only; 150 PSI (10.5
Kg/cm²) static when applied to both sides of the sensor simultaneously.
|
|
| POWER/OUTPUTS: Standard unit has selectable 110V AC 50/60 Hz, 220V AC 50/60 Hz, or 24V DC power. Included are an RS 232C and two set points. Set point SPDT relays rated 1 amp resistive @ 24V DC, .5 amp resistive @ 115V AC. | |
